TU 14-3-460-2003 Seamless steel tubes for boilers and pipelines
Standard: TU 14-3-460-2003
Equivalent Standards: TU 14-3R-55-2001, GB 5310, DIN 17175, ASTM A213, ASTM A335
Material: 12Ch18N12T
Equivalent Materials: X6CrNiTi18-10, 1.4541, TP321, S32100
Chemistry Composition
C, %
Si, %
Mn, %
P, %
S, %
Cr, %
Ni, %
Cu, %
0.12 max
0.80 max
1.00-2.00
0.030 max
0.020 max
17.0-19.0
11.0-13.0
0.30 max
Mechanical Properties
Tensile Strength , MPa
Yield Strength, MPa
Elongation, %
539-686
215-392
35 min
Outside Diameter & Tolerance
Hot rolled
Outside Diameter, mm
Tolerance
57≤OD≤219
±1%
Cold Drawn
Outside Diameter, mm
Tolerance
10≤OD≤30
±0.30mm
32≤OD≤50
±0.40mm
51≤OD≤76
±0.8%
Wall thickness & Tolerance
Hot rolled
Wall Thickness, mm
Tolerance
OD≤108, WT: All
+15%/-10%
OD>108, WT: All
+20%/-5%
Cold Drawn
Wall Thickness, mm
Tolerance
2≤WT≤12
±10%
Length: 4000mm; 8030mm; 8050mm; 12010mm; 12030mm; 12050mm; and so on.
Keyword: seamless steel pipe, seamless steel tube, boiler steel pipe, TU 14-3-460-2003
